Page #72 background imageLoading...
Page #72 background image
W415-2034 / A / 10.18.19
EN
72
replacement parts
Ref.
#
Description Part Number Stocked
LV38-1 LV50-2 LV62 LV74
1
Flex Connector (c/w Shut-Off)
W175-0217
Yes
2
Valve (NG)
W725-0056
Yes
Valve (P)
W725-0057
Yes
3
Control Board
W190-0177
Yes
4
Control Board Wiring Harness
W750-0276
Yes
5
Battery Holder (w/ switch)
W350-0655
Yes
6
3 Prong Light Pigtail
W750-0358
Yes
7
LED Light Assembly
W010-3661-SER W010-3652-SER W010-4079-SER W010-4078-SER
8
LED Glass Assembly
W010-3752-SER W010-3714-SER W010-4071-SER W010-4070-SER
9
LED Cover
W200-0543-SER W200-0499-SER W200-0653-SER W200-0652-SER
10
Burner Assembly (NG)
W100-0225-SER W100-0224-SER W100-0221-SER W100-0226-SER
Burner Assembly (P)
W100-0232-SER W100-0234-SER W100-0233-SER W100-0269-SER
11
Burner Orifi ce (NG)
W456-0038 W456-0034 W456-0031 W456-0030
Burner Orifi ce (P)
W456-0053 W456-0052 W456-0051 W456-0049
Yes
12
Media Tray Assembly
W010-4140-SER W010-4139-SER W010-4136-SER W010-4138-SER
13
Manifold (Flex)
W432-0533
14
Pilot Assembly (NG)
W010-2763
Yes
Pilot Assembly (P)
W010-2808
Yes
15
Pilot Housing
W350-0800-SER
16
PF2 Wire Harness
W750-0276
Yes
17
Media Cover Assembly
W010-4211-SER
18
Connector
W445-0038
Yes
19
Transformer
W707-0019
Yes
20
LED Wire (Black)
W750-0432 W750-0433
21
LED Wire (White)
W750-0430 W750-0401 W750-0430 W750-0401
22
LED Aux Wire
W750-0434
23
LED Controller
W190-0125
24
Bluetooth Wire Harness
W750-0435
25
Light, Accent (c/w gasket)
W405-0049-SER
Yes
26
Terminal
N/A W060-0008
Yes
27
Transformer (Night Light)
W707-0019 W707-0027
28
Bluetooth Module
W190-0090
Yes
29
Power Cord
W750-0294
