MASCHINE 1.5 Reference Manual – 208
Several Zones in the Mapping Tab
Mapping Tab: Controls
root
Select a root note in the root eld. The root note will be
highlighted in brown on the Keyboard; to change it, you
can also drag it to another note on the Keyboard.
low notE
Set the lowest note of the Zone by entering it here.
Alternatively, you can drag the left border of the Zone to
the lowest note. The note range of the selected Zone will
be marked on the Keyboard with a slightly lighter color.
hIGh notE
Set the highest note of the Zone by entering it here.
Alternatively, you can drag the right border of the Zone to
the highest note.
low vEl
This denes the lowest velocity for the Zone’s velocity
range. Set it by entering the value in the text eld or by
dragging the lower border of the Zone.
hIGh vEl
This denes the highest velocity for the Zone’s velocity
range. Set it by entering the value in the text eld or by
dragging the upper border of the Zone.
tUnE Set the tuning of the Zone in the Tune eld.
GaIn Set the gain of the Zone here.

Native Instruments Maschine Specifications

General

Weight	4.85 lbs (2.2 kg)
Pads	16 velocity-sensitive pads with aftertouch
Connectivity	USB, MIDI In/Out
Software	Maschine Software
Compatibility	Mac and PC
Power Supply	USB powered
Audio Interface	No built-in audio interface
Sequencer	Yes, pattern-based sequencer
Sampling	Yes, integrated sampler
Effects	Yes, includes a variety of effects
Encoders	8 knobs with LED ring indicators
DAW Integration	Yes, works as a plugin within most major DAWs
