Native Instruments Maschine Reference Manual

MASCHINE 1.5 Reference Manual – 47
2.5.2 Routing Tab
The Routing Tab of the Audio and MIDI Settings dialog
InpUtS
By clicking on this button, you can dene which two inputs
on your audio interface will be seen by MASCHINE. Select
the Inputs of your audio interface on the right column by
clicking on the elds: you will be presented with a dropdown
menu with all the available Inputs. The choices made here
will determine which Inputs can be used when sampling ex-
ternal sources, for example.
oUtpUtS
By clicking on Outputs, you will be presented with a list
of the eight stereo outputs from MASCHINE: in the right
column, you can assign them to the outputs of your audio
interface via a dropdown menu.

Native Instruments Maschine Specifications

General

Weight	4.85 lbs (2.2 kg)
Pads	16 velocity-sensitive pads with aftertouch
Connectivity	USB, MIDI In/Out
Software	Maschine Software
Compatibility	Mac and PC
Power Supply	USB powered
Audio Interface	No built-in audio interface
Sequencer	Yes, pattern-based sequencer
Sampling	Yes, integrated sampler
Effects	Yes, includes a variety of effects
Encoders	8 knobs with LED ring indicators
DAW Integration	Yes, works as a plugin within most major DAWs
