Native Instruments Maschine Reference Manual

MASCHINE 1.5 Reference Manual – 186
11.1 Controlling Sampling from the Hardware
11.1.1 Recording a Sample (Hardware)
Choose an empty Sound Slot to record into by selecting it with its Pad.
Now hit SAMPLING to enter Sampling Mode:
The Record Page on the hardware Displays
SoUrCE
You can select the Source by using Knob 1: it can be ei-
ther set to Extern for audio signals connected to your audio
interface, or Intern for audio signals from MASCHINE itself
(either from another Group or from the Master Output).
InpUt
Using Knob 2 you can choose between the available
Inputs. If Extern is selected, you can choose the external
input of MASCHINE: In 1 L, In 1 R, or In 1 L + R. If Intern
is selected you can select from the available Groups and
the Master as a source.
modE
MASCHINE offers two different modes for starting the re-
cording available via Knob 3.
dEtECt
If dEtECt is selected, you can set a certain thrEShold value
using Knob 4, and after pressing Start the input signal lev-
el exceeding this Threshold will start the recording. This is
useful to record a singer or an instrumentalist for example.

Native Instruments Maschine Specifications

General

Weight	4.85 lbs (2.2 kg)
Pads	16 velocity-sensitive pads with aftertouch
Connectivity	USB, MIDI In/Out
Software	Maschine Software
Compatibility	Mac and PC
Power Supply	USB powered
Audio Interface	No built-in audio interface
Sequencer	Yes, pattern-based sequencer
Sampling	Yes, integrated sampler
Effects	Yes, includes a variety of effects
Encoders	8 knobs with LED ring indicators
DAW Integration	Yes, works as a plugin within most major DAWs
