MASCHINE 1.5 Reference Manual – 165
9.4 Applying FX to an external instrument
Please make sure that you have connected an external audio signal source to your audio in-
terface and that the inputs of the audio interface are activated. To do this, open the Audio
and MIDI Settings… from the File Menu, activate the desired inputs by clicking on them,
then click OK:
MASCHINE's Inputs conguration in the Audio and MIDI Settings dialog
Audio signals coming from external sources will now be routed to MASCHINE’s FX section!
Hardware
1. Choose an empty Group by selecting it with one of the Group Buttons.
2. Select an empty Sound Slot by pressing one of the Pads, let’s say Pad 1, and then select
the Sound Tab by pressing Button 4.
3. Press Button 5 to select its Source Tab (SRC).
4. Press and hold SHIFT, followed by BROWSE. By using Buttons 5 & 6 or Knob 5 you can
select between Sampler, Input and MIDI Out.
5. Select Input and press Button 8 to conrm your selection.

Native Instruments Maschine Specifications

General

Weight	4.85 lbs (2.2 kg)
Pads	16 velocity-sensitive pads with aftertouch
Connectivity	USB, MIDI In/Out
Software	Maschine Software
Compatibility	Mac and PC
Power Supply	USB powered
Audio Interface	No built-in audio interface
Sequencer	Yes, pattern-based sequencer
Sampling	Yes, integrated sampler
Effects	Yes, includes a variety of effects
Encoders	8 knobs with LED ring indicators
DAW Integration	Yes, works as a plugin within most major DAWs
