NCR 7197 II SERIES User Manual

7197 Series II Owner’s Guide Chapter 6: Commands
August 2011
71
Code (Hexadecimal) Command Page
1D 56 m n Select Cut Mode and Cut Paper 85
1D 57 nL nH Set Printing Area Width 99
1D 5C nL nH Set Relative Vertical Print Position in Page
Mode
172
1D 5E r t m
Execute Macro
174
1D 61 n Determined if the device supports USU 148
1D 66 n Select Pitch for HRI Characters 154
1D 68 n Select Bar Code Height 154
1D 6B m d1…
Print Bar Code 155
1D 6B m n d1…dn Print Bar Code 155
1D 72 n Transmit Status 131
1D 77 n Select Bar Code Width 158
1D 28 6B pL pH cn 41
QR Code: Select the model
1D 28 6B pL pH cn 43
QR Code: Set the size of module
1D 28 6B pL pH cn 45
QR Code: Select the error correction level
1D 28 6B pL pH cn 50
QR Code: Store the data in the symbol
storage area
1D 28 6B pL pH cn 51
QR Code: Print the symbol data in the
symbol storage area
1D 28 6B pL pH cn 52
QR Code: Transmit the size information of
the symbol data in the symbol storage area
1D FF Reboot the Printer
196
1F 04 n Convert 6 Dots/mm Bitmap to 8 Dots/mm
Bitmap
125
1F 05 n Select Superscript or Subscript Modes 114
IF 11 [m n],[m n]…[m
n] 0FFH
Printer Setting Change
180
1F 56 Send Printer Software Version
136
1F 74 Print Test Form 86
1B 2B Select or Cancel Unicode(UTF)
114
