Configure Switching
116
S350 Series 8-Port Gigabit Ethernet Smart Managed Pro Switch Models GS308T and GS310TP
7. In the Group Operation menu, select one of the following options, which applies to all ports
in the VLAN:
• Untag All. For all ports and LAGs that are members of the VLAN, tags are removed
from all egress packets.
• T
ag All. For all ports and LAGs that are members of the VLAN, all egress packets are
tagged.
• Remove All.
All ports and LAGs are removed from the VLAN.
8. In the Ports table, click each port once, twice, or three times to configure one of the following
modes or reset the port to the default mode:
• T (T
agged). Selects the port as a tagged port in the VLAN. All frames transmitted on
the port are tagged for this VLAN.
• U (Untagged). Selects the port as an untagged port in the VLAN.
All frames
transmitted on the port are untagged for this VLAN.
• Blank.
The port is excluded from the VLAN.
By default, the selection is blank and none of the ports are a member of the VLAN.
(VLAN 1 is an exception. By default, all ports are untagged members of VLAN 1.)
9. In the LAG table, click each LAG once, twice, or three times to configure one of the following
modes or reset the LAG to the default mode:
• T (T
agged). Selects the LAG as a tagged LAG in the VLAN. All frames transmitted on
the LAG are tagged for this VLAN.
• U (Untagged). Selects the LAG as an untagged LAG in the VLAN.
All frames
transmitted on the LAG are untagged for this VLAN.
• Blank.
The LAG is excluded from the VLAN.
By default, the selection is blank and none of the LAGs are a member of the VLAN.
(VLAN 1 is an exception. By default, all LAGs are untagged members of VLAN 1.)
10. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable information displayed on the page.
Table 22. Advanced VLAN membership
Field Definition
VLAN Name The name for the VLAN that you selected. It can be up to 32 alphanumeric characters long,
including blanks.
The names for the following VLANs are predefined:
• VLAN 1. Default.
• VLAN 2. Auto-V
oIP.
• VLAN 4089. Auto-V
ideo.
VLAN Type The type of the VLAN you selected:
• Default (VLAN ID = 1).
Always present.
• Static. A
VLAN that you configured.
• Dynamic. A
dynamically created VLAN.
