Configure Switching
148
S350 Series 8-Port Gigabit Ethernet Smart Managed Pro Switch Models GS308T and GS310TP
5. Select Switching > Multicast > MFDB > MFDB Table.
6. In the Search by MAC Address field, enter a MAC address.
Enter six two-digit hexadecimal numbers separated by colons, for example
00:01:23:43:45:67.
7. Click the Go button.
If the address exists, the entry is displayed. An exact match is required.
Table 34. MFDB table information
Field Description
MAC Address The multicast MAC address for which you requested data.
VLAN ID The VLAN ID to which the multicast MAC address is related.
Type The type of the entry. Static entries are those that are configured by the end user.
Dynamic entries are added to the table as a result of a learning process or protocol.
Component The component that is responsible for this entry in the Multicast Forwarding Database.
The options are IGMP snooping, GMRP
, Static Filtering, and MLD snooping.
Description The text description of this multicast table entry. The options are Management
Configured, Network Configured, and Network
Assisted.
Forwarding Interfaces The resultant forwarding list is derived from combining all the forwarding interfaces and
removing the interfaces that are listed as the static filtering interfaces.
View the MFDB Statistics
 To view the MFDB statistics:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 11.
Your web browser might display a security message, which you can ignore. For more
information, see Access the Local Browser Interface on page 19.
The login window opens.
