NETGEAR GS308T User Manual

Monitor the System
293
S350 Series 8-Port Gigabit Ethernet Smart Managed Pro Switch Models GS308T and GS310TP
The following table describes the EAP statistics displayed on the page.
Table 61. EAP statistics
Field Description
Port The port number.
EAPOL Frames Received The number of valid EAPoL frames of any type that were received by this
authenticator
.
EAPOL Frames Transmitted The number of EAPoL frames of any type that were transmitted by this
authenticator
.
EAPOL Start Frames
Received
The number of EAPoL start frames that were received by this authenticator.
EAPOL Logoff Frames
Received
The number of EAPoL logoff frames that were received by this authenticator.
EAPOL Last Frame Version The protocol version number carried in the most recently received EAPoL frame.
EAPOL Last Frame Source The source MAC address carried in the most recently received EAPoL frame.
EAPOL Invalid Frames
Received
The number of EAPoL frames that were received by this authenticator in which
the frame type is not recognized.
EAPOL Length Error Frames
Received
The number of EAPoL frames that were received by this authenticator in which
the frame type is not recognized.
EAP Response/ID Frames
Received
The number of EAP response/identity frames that were received by this
authenticator
.
EAP Response Frames
Received
The number of valid EAP response frames (other than resp/ID frames) that were
received by this authenticator
.
EAP Request/ID Frames
T
ransmitted
The number of EAP request/identity frames that were transmitted by this
authenticator.
EAP Request Frames
T
ransmitted
The number of EAP request frames (other than request/identity frames) that
were transmitted by this authenticator.
Perform a Cable Test
You can test and view information about the cables that are connected to switch ports.
 To perform a cable test:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 11.

NETGEAR GS308T Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Master (outer) case width	214 mm
Master (outer) case height	312 mm
Master (outer) case length	474 mm
Master (outer) case weight	6110 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	6 pc(s)
Package type	Box
Package depth	270 mm
Package width	226 mm
Package height	64 mm
Package weight	750 g
Cables included	AC
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	No
Product color	Black
LED indicators	Activity, Link, Power
Country of origin	China
10G support	-
Multicast protocols	IGMP
Input current	1 A
DC input voltage	12 V
MAC address table	- entries
