Configure Switching
134
S350 Series 8-Port Gigabit Ethernet Smart Managed Pro Switch Models GS308T and GS310TP
The values can be from 0 to 65535. The default value is 0.
e. Forward BPDU while STP Disabled. Enable or disable the bridge protocol data unit
(BPDU) flood.
This setting specifies whether spanning tree BPDUs are forwarded while spanning
tree is disabled on the switch.
7. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable fields displayed on the page.
Table 26. STP Configuration status
Field Description
Global Settings
Configuration Digest Key The identifier used to identify the configuration currently being used.
STP Status
Bridge Identifier The bridge identifier for the CST. It is made up using the bridge priority and
the base MAC address of the bridge.
Time Since Topology Change The time in day-hour-minute-second format since the topology of the CST
last changed.
Topology Change Count The number of times that the topology changed for the CST.
Topology Change The value of the topology change setting for the switch that indicates if a
topology change is in progress on any port assigned to the CST
. The option
is True or False.
Designated Root The bridge identifier of the root bridge. It consists of the bridge priority and
the base MAC address of the bridge.
Root Path Cost The path cost to the designated root for the CST.
Root Port The port to access the designated root for the CST.
Max Age (secs) The maximum age timer controls the maximum length of time in seconds
that passes before a bridge port saves its configuration BPDU information.
Forward Delay (secs) The derived value of the Root Port Bridge Forward Delay setting.
Hold Time (secs) The minimum time in seconds between the transmission of configuration
BPDUs.
CST Regional Root The priority and base MAC address of the CST regional root.
CST Path Cost The path cost to the CST tree regional root.
