56
GS728TS, GS728TPS, GS752TS, and GS752TPS Gigabit Smart Switches
5. To view information received from a partner link, select the port connected to the remote
device from the Interface menu in the Remote Device Information area.
The page refreshes and shows the information in the following table if LLDP data has
been received on the interface
Field Description
Remote ID Specifies the remote client identifier assigned to the remote system.
Remote Tw_sys_tx
(uSec)
Integer that indicates the value of Tw_sys that the remote system can support.
Remote Tw_sys_tx
Echo (uSec)
Integer that indicates the value Transmit Tw_sys echoed back by the remote
system.
Remote Tw_sys_rx
(uSec)
Integer that indicates the value of Tw_sys that the remote system requests from
the local system.
Remote Tw_sys_rx
Echo (uSec)
Integer that indicates the value of Receive Tw_sys echoed back by the remote
system.
Remote Fallback
Tw_sys (uSec)
Integer that indicates the value of fallback Tw_sys that the remote system is
advertising.
6. Click Clear to reset the counters on the page to their default values.
7. Click Refresh to update the page with the current information.
Tx_dll_ready Data Link Layer ready: This variable indicates that the tx system
initialization is complete and is ready to update/receive LLDP PDUs
containing EEE TLV.
Rx_dll_enabled Status of the EEE capability negotiation on the local system.
Rx_dll_ready Data Link Layer ready: This variable indicates that the rx system
initialization is complete and is ready to update/receive LLDP PDUs
containing EEE TLV.
Time Since Counters Last
Cleared
Time Since Counters Last Cleared (since the time of power up, or after
EEE counters are cleared).
Field Description
