Physical Description
User Manual for EL170/970/470 IP Satellite Modulator/
Demodulator/Modem
version 4.2
49
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
Connector Back Panel 06 / Description
Connector Technical Specifications Signalling Type
1. IFL IN SMA (Female) 50 Ohm L-band input, looped to Mod out of BP01
