Connector Back Panel 06 / Description
2. IFL OUT N-Connector (Female) 50 Ohm L-band + 10MHz + DC (12V, 24V, 48V)
The following DC voltages can be selected:
• 12V
• 24V
• 48V
The maximum current on this connector
is 3A.
Use a coax cable rated for the voltage
and current marked on the device.
Switch of the power of the device before
connecting the coax cable.
This to reduce the risk of personal injury
from electric shock or damage to the
device.
The following parameters must be enabled
in the device:
• ODU communication control
• Outdoor power supply
Set the parameters on the following
location. (Setting parameters refer to
chapter 5.)
EL >> Unit >> Control >> Outdoor Unit
