Nikon COOLSCAN V ED - 3. Lens cover

VRA53801 - R.3609.A
- A
2・
LS-50 -
・Hook the FPC of the AF unit (2) on the backside of the scan block unit (1) at the above ( 〇 ) position.
3. Lens cover
・Check if there is no dust on the whole lens cover (2).
・Attach the lens cover on the mechanical body unit (1) by entering the bosses into the 2 concavities of
( 〇 ) parts and the 2 holes of ( 〇 ) parts.
Hook here
①
②
Hole
凹
