Nikon COOLSCAN V ED User Manual

VRA53801 - R.3609.A
- A
21 ・
LS-50 -
29. Rail perforation sensor harness
・Connect the harness (3 lines) of the rail perforation sensor unit (2) and the harness (2 lines) of the lid
release SW (3) to the main PCB unit (1) as shown by ( 〇 ).
30. PS insulating plate
・Make a valley fold along the line of ( ) of the PS insulating plate (1), and frame it by hooking at
( 〇 ) part.
・Push the PS insulating plate (1) in the chassis (2) downwards as shown by ( ), and assemble them.
① ②
③
①
①
Push the insulating
plate in
downwards.
①
②
①
