NMC-WOLLARD 140 - Page 329

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M140 Tow Tractor Manual No. 46054
PAGE 4-129
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature E󰀨 Units
Per
Assy
57-
46550-9 HYD ASSY,M140,QSB4.5 1
46482 PUMP ASSY,GEAR,4B4.5T3 1
46530 STEERING ASSY, M140 HYDRAULIC 1
1
46420 MASTER CYLINDER W/BOOSTER REF
2
F104402 Ftg, 06-06FJX 90 1
3
NW036560 FTG, HYD, 08MB-06MJ90 1
4
3.2519 FTG, HYD, 06MJ-06MB 2
5
F100979 5406 CLAMP,HOSE,#6,.44-.78 (79470) 10
6
F104402 FTG, 06-06FJX90 2
7
1011081 CYLINDER, STEERING 2B 7.4 ST 1
8
44738 LSP151-05-01 GAUGE,SIGHT PLUG,3/4 NPT (LUBE DE
VICES)
1
9
8796.108 HOSE ASSY, #6M 42.38" ST/90 2
10
38828 HOSE ASSY, PS, #6M, 30.5" 1
11
1.7864 STEER UNIT, 5.9 CI 1
15
NW26799 FF5300-0645 FTG, HYD,ELL,PRESSURE (01276) 1
16
3.1572 6/6/2404 FTG,HYD,06MJ-06MP (V00565) 1
F101847 FTG, 06MJ-16MJ 2
3.1572 FTG,HYD,06MJ-06MP (V00565) 2
17
FTG, TEE 1
18
1
19
NW029020 VALVE,RELIEF,INLINE,ADJ,1100PS
(V00534)
1
20
3.1317 FTG, HYD, O8MJ-06MP90 (not as illustrated) 1
21
8797.105 HOSE ASSY #8M 24” ST/90 1
8797.104 HOSE ASSY 1
22
1.8808 FTG,HYD,06H-06FJX (01276) 2
23
F101679 D13KG61160 HOSE 0.37 ID X 0.66 OD LOW AR
24
46658 TANK WLDMNT,HYD,1.75 GAL,M140 1
25
202993 BREATHER,3/4 NPT,STL 1
26
BRKT,HYD TANK, LH (NOT USED) 0
28
3.1391 5602-06-06-06 FTG,HYD,TEE,06MP-06FP-06FP (V00565) 1
29
46247 6/6/4501 FTG,HYD,06H-06MP90 (V00565) 1
30
BRKT,HYD TANK, RH (NOT USED) 0
31
3.0143 12/12/2501 FTG,HYD,12MJ-12MP90 (V00565) 1
32
46240.2 HOSE ASSY,#12L, 15.5",ST/90 1
46420.5 HOSE ASSY 1
33
F101258 6801-12-16-NOW FTG,HYD,12MJ-16MB90 (V00565) 1
34
91926 6801-08-10-NOW FTG,HYD,08MJ-10MB90 (V00565) 1
35
F002691 FTG,P,TEE,06 MALL 1
36
46624 26004-LZA PUMP,HYD.GEAR,.66CID,SAE”A”11T
(15605)
1
43834 102930-000 GASKET,HYD PUMP,SAE A-2BOLT (15605) 1
37
202735 STEERING WHEEL, 14" 1
38
202736 BUTTON, HORN FOR VIP WHEEL 1
39
150526 NUT, 13/16-20 HEX 1
41
NW035372 COLUMN, STEERING, 10" 1
42
F103213 CLAMP, 1.75 ID MUFFLER 1
43
46642 COVER PLATE, ORBITROL 1
44
NW034968 TIE ROD END 3/4-16 RH 2
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2009
