Nokia N96 Service Manual

RJ-104 Rework jig
RJ-104 is a rework jig used when servicing the BTHFM module. It is
used together with rework stencil ST-37.
RJ-105 Rework jig
RJ-105 is a jig used for soldering and as a rework jig for the engine
module. It is used together with the ST-38 stencil.
RJ-157 Rework jig
RJ-157 is a jig used for soldering and as a rework jig for the engine
module. It is used together with the ST-55 stencil.
RJ-159 Rework jig
RJ-159 is a jig used for soldering and as a rework jig for the engine
module. It is used together with the ST-53 stencil.
