Page 170 of 206 Appendix A: WLAN Application Gateway 2246
553-3001-304 Standard 3.00 September 2004
Gateway 2246 writes Syslog format diagnostic messages to the
Syslog server.
• SNTP server – can be configured as a hostname, IP address, or
NONE. The SNTP server is a Simple Network Time server. The
WLAN Application Gateway 2246 obtains the current date and time
from the SNTP server and tags syslog messages with the date.
• IGMP Enabled – configure as Yes or No. IGMP is Internet Group
Routing Protocol. IGMP Enabled allows the WLAN Application
Gateway 2246 to join multicast groups. Enable this option if the
network switch connected to the WLAN Application Gateway 2246
requires IGMP for multicast traffic to be forwarded.
• Maintenance Lock – the system sets this option to Yes after
maintenance activities have been performed that require a reset.
This option cannot be changed. It is automatically set. Reset the
system at exit to clear Maintenance Lock. Maintenance Lock
prevents any new calls from starting.
3 Press ESC to return to the NetLink OAI System screen.
4 Reset the WLAN Application Gateway 2246.
End of Procedure
Connecting to the LAN
Follow the steps in Procedure 21 to connect the WLAN Application Gateway
2246 to the LAN.
Procedure 21
Connecting the WLAN Application Gateway 2246 to the LAN
1 Using an RJ-45 cable, connect the NETWORK port of the
WLAN Application Gateway 2246 to the connecting port on the Ethernet
switch.
2 Power up the entire system.
End of Procedure
All components should cycle through their usual diagnostic routine.
