Page 186 of 206 Appendix A: WLAN Application Gateway 2246
553-3001-304 Standard 3.00 September 2004
Viewing Telephone Line Status
The Telephone Line Status screen displays which wireless handsets are
communicating with the WLAN Application Gateway 2246.
From the System Status Menu screen, select Telephone Line Status. The
WLAN Application Gateway 2246 displays up to 16 telephone lines at one
time. See Figure 35. Move to the next group of 16 lines by using the arrow
keys.
Figure 35
Telephone Line Status screen
The following information is displayed on the Telephone Line Status
screen:
• WT MAC – the MAC address of the WLAN Handset 2210/2211 that
was entered when the wireless handset was configured.
