Page 158 of 206 Appendix A: WLAN Application Gateway 2246
553-3001-304 Standard 3.00 September 2004
Figure 19
Ethernet switch connections
Front panel
There are two different WLAN Application Gateway 2246 models with
similar front panel indicators. Refer to Figure 20 and Figure 21 on page 159.
The MOG6xx model supports up to 64 users.
Nortel Networks
Internet Telephones
Ethernet switch
Access Point
Access Point
optional
Nortel Networks IP
Telephony System
Ethernet cable
Phone cable
TFTP Server
Wireless
Telephones
Wireless
Telephones
WLAN IP Telephony
Manager 2245
WLAN Application
Gateway 2246 (optional)
Other
Wireless
Device
PSTN
or
PBX
Application Server
