Nortel 2245 - Saving the Configuration

Page 76 of 206 WLAN IP Telephony Manager 2245 configuration
553-3001-304 Standard 3.00 September 2004
• SendAll – in a system with multiple WLAN IP Telephony Managers
2245, the SendAll option is provided to speed configuration and ensure
identical settings. The S=SendAll option enables configuration
parameters of the selected field to be sent to every WLAN IP Telephony
Manager 2245 on the LAN. SendAll can only be used after the IP address
is configured on each WLAN IP Telephony Manager 2245 using a serial
connection. If identical configuration parameters are to be used for all
WLAN IP Telephony Managers 2245, configure only the IP address and
custom hostname (if desired) on each WLAN IP Telephony Manager
2245 using the initial serial connection. Then connect through the LAN
to this WLAN IP Telephony Manager 2245 and use SendAll to transmit
identical configuration options of each field for all WLAN IP Telephony
Managers 2245.
Saving the configuration
Reset the WLAN IP Telephony Manager 2245 in order to save the
configuration parameters. Follow the steps in Procedure 6 to save the
configuration.
Procedure 6
Saving the configuration
1 Press Esc on the keyboard.
If the WLAN IP Telephony Manager 2245 is in Maintenance Lock, a
prompt appears asking if the configuration is to be saved.
2 Enter
Y.
IMPORTANT!
If SendAll is used on the system, all passwords must be identical. Do not
change the password at the initial configuration if the SendAll option will
be used. Use the default password and change it globally if desired after
a LAN connection is established for all WLAN IP Telephony 2245s.
If independent administration of each WLAN IP Telephony Manager
2245 is desired, the passwords can be set during initial configuration.
