Page 160 of 206 Appendix A: WLAN Application Gateway 2246
553-3001-304 Standard 3.00 September 2004
• Status LEDs – indicate system messages and status. Refer to Figure 20
on page 159.
— 1 – heartbeat, indicates the WLAN Application Gateway 2246 is
running
— 2, 3, and 4 – currently unused
— 5 – System master
Installation
Installing with a new system
If this is a new system installation, complete Procedure 17 on page 160 when
the rest of the system is tested.
Installing in an existing system
If the WLAN Application Gateway 2246 is being added to an existing system,
the entire system must be reset before the WLAN Application Gateway 2246
can be used.
Follow the steps in Procedure 17 to install the WLAN Application Gateway
2246.
Procedure 17
Installing the WLAN Application Gateway 2246
1 Place the WLAN Application Gateway 2246 on a shelf or convenient
location.
Note: The WLAN Application Gateway 2246 is physically connected to
the Ethernet switch and can be placed in any convenient location within
325 ft (100 m) of the switch. It can also be rack-mounted.
2 Connect the power plug from the WLAN Application Gateway 2246’s
power adapter to the power jack on the front (or rear) of the box.
IMPORTANT!
Use only the power adapter provided by Nortel Networks.
