Page 61 of 206
WLAN IP Telephony Installation and Configuration
66
Installation
Contents
This chapter contains information on the following topics:
Required materials. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Supplied equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Pre-installation checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Installing the WLAN IP Telephony Manager 2245 . . . . . . . . . . . . . . . 63
About the front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Wall mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Rack-mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Connecting to the LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Connecting to the power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Installing the WLAN Application Gateway 2246. . . . . . . . . . . . . . . . . 66
Required materials
The following equipment must be provided by the customer:
• power outlet(s) – must accept the provided AC adapter, one for the
WLAN IP Telephony Manager 2245 and one for the WLAN Application
Gateway 2246 (if used).
• plywood backboard space – the WLAN IP Telephony Manager 2245 is
designed to be wall-mounted to ¾” plywood securely screwed to the
wall.
or
optional WLAN IP Telephony Manager 2245 rack-mount kit (must be
ordered separately), containing mounting plates and screws
