Page 172 of 206 Appendix A: WLAN Application Gateway 2246
553-3001-304 Standard 3.00 September 2004
The WLAN Application Gateway 2246 uses the following pins on the
connector.
Connect to the Application Server through the LAN
The IP address must be configured for the WLAN Application Gateway 2246
to function on the LAN. Follow the application’s instructions to identify the
WLAN Application Gateway 2246 to the application.
Figure 27
WLAN Application Gateway 2246 connection to Application Server through the LAN
Table 22
Pins on the connector
Pin Function
1 Carrier Detect
2 Data OAI Receives
3 Data OAI Transmits
5 Ground
7 Ready to Send
8 Clear to Send
LAN
Ethernet
switch
Application
Serve
(PC)
WLAN Application
Gateway 2246
