Nvidia JETSON XAVIER NX Design Guide

Introduction
NVIDIA Jetson Xavier NX DG-09693-001_v1.7 | 2
Table 1-1. Abbreviations and Definitions
Abbreviation
Definition
CAN Controller Area Network
CEC Consumer Electronic Control
CSI Camera Serial Interface
Diff Differential
DP DisplayPort
eDP Embedded DisplayPort
ESD Electrostatic Discharge
eMMC Embedded MMC
EMI Electromagnetic Interference
FET Field Effect Transistor
GPIO General Purpose Input Output
HDCP High-bandwidth Digital Content Protection
HDMI High Definition Multimedia Interface
I2C Inter IC Interface
I2S Inter IC Sound Interface
LCD Liquid Crystal Display
LDO Low Dropout (voltage regulator)
LPDDR4x Low Power Double Data Rate DRAM, Fourth generation
MDI Medium-Dependent Interface
MIL 1/1000th of an inch
MIPI Mobile Industry Processor Interface
mm Millimeter
PCIe Peripheral Component Interconnect Express interface
PCM Pulse Code Modulation
PHY Physical Interface (that is, USB PHY)
ps Pico-Seconds
PMIC Power Management Integrated Circuit
RJ45 8P8C modular connector used in Ethernet and other data links
RTC Real Time Clock
SD Card Secure Digital Card
SDIO Secure Digital I/O Interface
SE Single-Ended
SPI Serial Peripheral Interface
TMDS Transition-Minimized Differential Signaling
UART Universal Asynchronous Receiver-Transmitter
USB Universal Serial Bus

Nvidia JETSON XAVIER NX Specifications

General

Storage	16 GB eMMC 5.1
AI Performance	21 TOPS (INT8)
Operating Temperature	-25°C to 80°C
Operating System	Linux (JetPack SDK)
GPU	NVIDIA Volta architecture with 384 CUDA cores and 48 Tensor cores
CPU	6-core NVIDIA Carmel ARMv8.2 64-bit CPU 6 MB L2 + 4 MB L3
Memory	8GB 128-bit LPDDR4x
Video Decode	2x 4K60 | 4x 4K30 | 8x 1080p60 | 16x 1080p30 (H.265/H.264)
Camera	Up to 6 cameras
Connectivity	Gigabit Ethernet, M.2 Key E for Wi-Fi/Bluetooth
Power	10 W / 15 W / 20 W
Dimensions	70mm x 45mm
