NVIDIA Jetson Xavier NX DG-09693-001_v1.7 | 80
Table 13-2. Pins with External Pull-ups to Supply on before SYS_RESET*
Inactive
Jetson Xavier NX
Pin
Pull-up Supply
Voltage (V)
External
Pull-up (kΩ)
Jetson Xavier NX
Pin
Pull-up Supply
Voltage (V)
External
Pull-up (kΩ)
I2C0_SCL/SDA 3.3 2.2 SPI1_CS0* 1.8 100
I2C1_SCL/SDA 3.3 2.2 SPI1_CS1* 1.8 100
I2C2_SCL/SDA 1.8 2.2
PCIE[1:0]_CLKREQ
*
3.3 47
CAM_I2C_SCL/SDA 3.3 2.2 PCIE[1:0]_RST* 3.3 4.7
PCIE_WAKE*N 3.3 47
