Power
NVIDIA Jetson Xavier NX DG-09693-001_v1.7 | 16
Figure 5-6. Power Down (Sudden Power Loss)
POWER_E N
SHUT DOW N_REQ*
VDD_IN 3.0V
T > 10mS
Note: SHUTDOWN_REQ* must always be serviced by the carrier board to toggle POWER_EN
from high to low, even in cases of sudden power loss.
