Nvidia JETSON XAVIER NX Design Guide

Display
NVIDIA Jetson Xavier NX DG-09693-001_v1.7 | 45
Table 8-4. eDP and DP Signal Connections
Module Pin Name
Type
Termination
Description
DPx_TXD[3:0]_N/P O Series 0.1uF capacitors and ESD to
GND
on
all.
eDP/DP Differential CLK/Data Lanes:
Connect to matching pins on display
connector.
DPx_AUX_N/P I/OD Series 0.1uF capacitors. 100kΩ pulldown on
DP0_AUX_P and 100kΩ pull-up to
VDD_3V3_SYS on DP0_AUX_N. ESD to
GND
on both.
eDP/DP: Auxiliary Channels: Connect to
AUX_CH
-/+ on display connector.
DPx_HPD I
Level shifter (1.8V on module side, 3.3V on
DP/eDP connector side) and ESD to
GND
..
eDP/DP: Hot Plug Detect: Connect to
HPD
pin on display connector through level shifter.
8.2 HDMI
A standard DP 1.2a or HDMI V2.0 interface is supported. See Figure 8-7 for more details.

Nvidia JETSON XAVIER NX Specifications

General

Storage	16 GB eMMC 5.1
AI Performance	21 TOPS (INT8)
Operating Temperature	-25°C to 80°C
Operating System	Linux (JetPack SDK)
GPU	NVIDIA Volta architecture with 384 CUDA cores and 48 Tensor cores
CPU	6-core NVIDIA Carmel ARMv8.2 64-bit CPU 6 MB L2 + 4 MB L3
Memory	8GB 128-bit LPDDR4x
Video Decode	2x 4K60 | 4x 4K30 | 8x 1080p60 | 16x 1080p30 (H.265/H.264)
Camera	Up to 6 cameras
Connectivity	Gigabit Ethernet, M.2 Key E for Wi-Fi/Bluetooth
Power	10 W / 15 W / 20 W
Dimensions	70mm x 45mm
