Nvidia JETSON XAVIER NX Design Guide

NVIDIA Jetson Xavier NX DG-09693-001_v1.7 | 64
Chapter 11. Audio
Xavier supports multiple PCM and I2S audio interfaces. It also includes a flexible audio port
switching architecture.
Table 11-1. Audio Pin Descriptions
Pin #
Module Pin
Name
Xavier Signal Usage/Description
Recommended
Usage
Directio
n
Pin Type
199 I2S0_SCLK DAP5_SCLK I2S Audio Port 0 Clock
Audio Device
Bidir
CMOS –
1.8V
197 I2S0_FS DAP5_FS I2S Audio Port 0 Left/Right Clock Bidir
193 I2S0_DOUT DAP5_DOUT I2S Audio Port 0 Data Out
Output
(note)
195 I2S0_DIN DAP5_DIN I2S Audio Port 0 Data In
Input
(note)
226 I2S1_SCLK DAP3_SCLK I2S Audio Port 1 Clock
Audio Device
(i.e. M.2 Key E)
Bidir
224 I2S1_FS DAP3_FS I2S Audio Port 1 Left/Right Clock Bidir
220 I2S1_DOUT DAP3_DOUT I2S Audio Port 1 Data Out
Output
(note)
222 I2S1_DIN DAP3_DIN I2S Audio Port 1 Data In
Input
(note)
211 GPIO09 AUD_MCLK GPIO #9 or Audio Codec Clock Audio Device
Output
(note)
Notes:
1. In the Type/Dir column, Output is from Jetson Xavier NX. Input is to Jetson Xavier NX. Bidir is for Bidirectional signals.
2. The direction indicated for I2S[1:0]_DOUT and _DIN are associated with their use as I2S data lines. The direction for GPIO09 is
associated with its use as Audio Clock. The pins support GPIO functionality, so support both input and output operation
(bidirectional).

Nvidia JETSON XAVIER NX Specifications

General

Storage	16 GB eMMC 5.1
AI Performance	21 TOPS (INT8)
Operating Temperature	-25°C to 80°C
Operating System	Linux (JetPack SDK)
GPU	NVIDIA Volta architecture with 384 CUDA cores and 48 Tensor cores
CPU	6-core NVIDIA Carmel ARMv8.2 64-bit CPU 6 MB L2 + 4 MB L3
Memory	8GB 128-bit LPDDR4x
Video Decode	2x 4K60 | 4x 4K30 | 8x 1080p60 | 16x 1080p30 (H.265/H.264)
Camera	Up to 6 cameras
Connectivity	Gigabit Ethernet, M.2 Key E for Wi-Fi/Bluetooth
Power	10 W / 15 W / 20 W
Dimensions	70mm x 45mm
