Nvidia JETSON XAVIER NX Design Guide

Display
NVIDIA Jetson Xavier NX DG-09693-001_v1.7 | 39
Pin #
Module Pin
Name
Xavier Signal Usage/Description
Recommended
Usage
Direction Pin Type
77 DP1_TXD2_P
HDMI_DP1_TXDP2
81 DP1_TXD3_N
HDMI_DP1_TXDN3
DisplayPort 1 Lane 3 or HDMI Clk Lane
83 DP1_TXD3_P
HDMI_DP1_TXDP3
96 DP1_HPD
DP_AUX_CH1_HP
D
Display Port 1 or HDMI Hot Plug Detect.
Must be active high for DP. For HDMI, the
polarity can be changed in SW.
Input
CMOS –
1.8V
94 HDMI_CEC HDMI_CEC HDMI CEC Bidir
Open
Drain,
1.8V
Notes:
1. In the Type/Dir column, Output is from Jetson Xavier NX. Input is to Jetson Xavier NX. Bidir is for Bidirectional
signals.
2. The direction shown in this table for DP_AUX_CH[1:0]_HPD is true when used for Hot-plug Detect. Otherwise, if
used as GPIOs, the direction is bidirectional.
A standard DP 1.4 or HDMI V2.0 interface is supported. These share the same set of interface
pins, so either DisplayPort or HDMI can be supported natively.
Table 8-2. DP and HDMI Pin Mapping
Module Pin Name
Module Pin #s
HDMI
DP
DP[1:0]_TXD3_P
DP[1:0]_TXD3_N
83 / 59
81 / 57
TXC+
TXC –
TX3+
TX3–
DP[1:0]_TXD2_P
DP[1:0]_TXD2_N
77 / 53
75 / 51
TX0+
TX0–
TX2+
TX2–
DP[1:0]_TXD1_P
DP[1:0]_TXD1_N
71 / 47
69 / 45
TX1+
TX1–
TX1+
TX1–
DP[1:0]_TXD0_P
DP[1:0]_TXD0_N
65 / 41
63 / 39
TX2+
TX2–
TX0+
TX0–

Nvidia JETSON XAVIER NX Specifications

General

Storage	16 GB eMMC 5.1
AI Performance	21 TOPS (INT8)
Operating Temperature	-25°C to 80°C
Operating System	Linux (JetPack SDK)
GPU	NVIDIA Volta architecture with 384 CUDA cores and 48 Tensor cores
CPU	6-core NVIDIA Carmel ARMv8.2 64-bit CPU 6 MB L2 + 4 MB L3
Memory	8GB 128-bit LPDDR4x
Video Decode	2x 4K60 | 4x 4K30 | 8x 1080p60 | 16x 1080p30 (H.265/H.264)
Camera	Up to 6 cameras
Connectivity	Gigabit Ethernet, M.2 Key E for Wi-Fi/Bluetooth
Power	10 W / 15 W / 20 W
Dimensions	70mm x 45mm
