that is able to be changed will flash its underline segment on
and off. This flashing segment is called the CURSOR and
Knob #1 permits you to move the cursor back and forth to
select the character to be changed.
Once you have located the character to be changed, the
CHARACTER Knob #3 allows you to select the desired
character for that segment. The MATRIX-12 provides the 26
letters of the English Alphabet, numerals 0 through 9, a
BLANK character for spaces and 27 miscellaneous
characters including various punctuation marks.
MODULATION
ROUTINGS Since the modulation capabilities of the MATRIX-12 are so
extensive, it is very likely that you could lose track of all the
Modulation Pages that were used in creating the Patch. This
Sub-Page is provided to assist you in examining the current
modulations of any Patch in the form of a summary list.
MODULATION ROUTINGS
MOD
SOURCE AMOLNTDBT
17
RVEL -54 ENV2REL
When MODULATION ROUTINGS is selected, the PAGE
MODIFIER will display a list of the MATRIX MODULATION
routings in the Patch. Each routing is indexed under the
MOD heading and turning Knob #1 counter-clockwise will
permit you to run through the list in descending order. Each
MATRIX MOD Page will be displayed showing its SOURCE,
AMOUNT and DEST
You are also permitted to edit the current modulations while
in this Page. Although the SOltf?CEcannot be changed
and new Modulation Pages cannot be created, you are
premitted to change the AMOUNT (using Knob #4) and
DES7(using Knob #5) of the current Mod Pages as you
need. You can also remove a modulation by pressing and
holding the button beneath the Source display in the Lower
window and pressing CLEAR in X SELECT. If you use this
method to remove all the modulations, the Upper Display will
show the message:
NO MODULATIONS IN THIS PATCH
140 Matrix-12 Owner's Manual
