the STEP Number is pressed, the number in the display becomes
underlined and you can select among the 100 Steps using the X
SELECT buttons.
As mentioned above, if SLAVEls selected in the ENABLE
parameter, the PROGRAMMER window will also display the current
Patch selected in each STEP Number.
MODE This parameter is used to select a SINGLE Patch or a MULTI Patch
to be programmed in the current STEP. The button beneath the
MODE display or Knob #5 can be used to select between a SINGLE
Patch or a MULTI Patch.
PATCH This parameter is used to select the desired Patch Number for the
current STEP from 00 to 99. If the current MODE is a SINGLE
Patch, the number selected will be the SINGLE Patch Number for
that STEP. If the current MODE is a MULTI Patch, the number
selected will be the MULTI Patch Number for that STEP.
Knob #5 is used to advance or reverse through the Patch Numbers
in order to select the PATCH. Also, if the button beneath the
PATCH Number is pressed, the number in the display becomes
underlined and you can select among the 100 Patches using the X
SELECT buttons.
MIDI Patch Changes -
Operation with another MATRIX-12 or the Oberheim XPANDER
• When using the MIDI Patch Change function, both Oberheim instruments
must have SYSTEMX (System Exclusive) and PATCH in the MIDI
ENABLES Sub-Page in order for the Slave Oberheim to respond to the
Master's switching between SINGLE Patch Mode and MULTI Patch Mode.
• SYSTEMX must also be enabled on both the Master and Slave Oberheim
instruments for MIDI Patch Changes to occur when using the ADVANCE CHAIN
footswitch or the V and"-" buttons on the Master Oberheim.
• If CHAIN is being used on the Master Oberheim, it will send MIDI Patch
Numbers to the Slave Oberheim on the BASIC CHANNEL when the
ADVANCE CHAIN footswitch or the V and"-" buttons are used. Just be sure
that PATCHand SYSTEMXare enabled for both instruments. If
SYSTEMX is disabled on either the Master or the Slave Oberheim, the Slave
will not respond at all to Patch Changes made fromthe Master in CHAIN.
MIDI Patch Changes -
Operation with Other Instruments
• Patch Changes made on the MATRIX-12 in CHAINare not transmitted via
MIDI unless System Exclusive is enabled in the MIDI ENABLES Sub-Page.
Since the receiving instrument must be another Oberheim -orone that has
the Oberheim System Exclusive code programmed, Patch Changes made in
CHAIN will not be recognized by other manufacturers1 equipment.
Matrix-12 Owner's Manual 53
