6 System diagram
1 2
4
3
5
6
7
9
VS20-BU
VS200 Slide Scanner Base Unit for Single Tray Loading
8
5
VS20-POWSUP
VS200 Power Supply
4
VS20-LIQDIS
Oil dispenser System
3
VS20-CAM-COVER
VS200 Intermediate Part
to Cover the B/W Camera
7
VS20-BU-L
VS200 Slide Scanner
Base Unit for Loader
8
VS20-LOADER
VS200 Slide Loader Unit
10
VS20-LOAD-UG
VS200 Slide Loader
Upgrade for Single Tray
Loading Units
10
2
VS20-304M
FL camera VS304M
HAMAMATSU C13440-
20CU
Hamamatsu Orca Flash 4.0
V3
Hamamatsu Orca Fusion
1
VS20-FL-A
Fluorescence excitation
lter wheel and white light
LED
VS20-FL-B
Fluorescence excitation and
emission lter wheels and
white light LED
VS20-FL-C
Fluorescence emission lter
wheels and switchable LED
VS20-FL-D
Fluorescence with
switchable LED only
6
VS20-ST13
VS200 SlideTray
(1”x 3”)
VS20-ST13X5
VS200 SlideTray
(set of 5 trays for
1”x3” slides)
VS20-ST23
VS200 SlideTray
(2”x3”)
VS20-ST34
VS200 SlideTray
(3”x4”)
VS20-ST45
VS200 SlideTray
(4”x5”)
7
Fluorescence Cameras
Fluorescence Solution
Additional Tray Solutions
Additional Objective Solutions
VS200 system diagram
Loader Options
Standard Setup Single Tray Loading Unit
Front view Rear view
XAPO/SAPO Objective
10X
UPLXAPO10X
40X
UPLXAPO40X
40X
UPLXAPO40XO
60X
UPLXAPO60XO
60X
UPLSAPO60XS
100X
UPLXAPO100XO
100X
UPLSAPO100XS
PH Objective
4X UPLFLN 4XPH
10X UPLFLN 10X2PH
20X UPLFLN 20XPH
40X UPLFLN 40XPH
60X UPLFLN 60XOIPH
100X UPLFLN 100XO2PH
6.1 Available fluorescence components
The VS200 system can be ordered with four different fluorescence sets. Each set con-
tains a basic configuration plus individual components. Filter sets and cameras are
not part of the configuration.
Remark: Configuration C and D are not available in all countries.
Basic configuration
Component A B C D
IX3-RFACA X X X X
IX3-RFALFE X X X X
UPFLN4X object-
ive
X X X X
U-FF, filter cube
(empty)
X X X X
Individual components
- 20 -
Instructions for use
6 System diagram
