(1) camera
(2) tighten rotation locking screw
(3) U-FFWO
5. As a final step, adjust orientation and parfocality of the camera, and then
lock the camera via counternut to prevent accidential de-adjustment.
How to adjust the camera adapter (tubus) is described in chapter Camera adapter
auf Seite 139.
11.4 X-Cite adapter
The units described below must be assembled and adjusted by Olympus. If these units are
assembled or adjusted by the customer, the operations are not ensured.
Hex key (3.0mm)
X-Citeadapter
- 56 -
Instructions for use
11 Mounting fluorescence components
OLYMPUS VS200 System
