11 Mounting fluorescence components
The units described below must be assembled and adjusted by Olympus. If these units are
assembled or adjusted by the customer, the operations are not ensured.
Skip this chapter if you have a brightfield system only.
In the box with the fluorescence components (A, B, C or D) you find all parts needed
to setup fluorescence for the VS200 system. Carefully unbox all components and fol-
low the instructions.
11.1 IX3-RFACA and IX3-RFALFE
The units described below must be assembled and adjusted by Olympus. If these units are
assembled or adjusted by the customer, the operations are not ensured.
3 mm and 4 mm hex key
1. Assemble the IX3-RFACA and IX3-RFALFE as shown in the image below
and hand-tighten the two 3 mm hex socket screws at the junction.
- 40 -
Instructions for use
11 Mounting fluorescence components
OLYMPUS VS200 System
