8 Specifications
VS200 Single Tray Load (STL)
VS200 Multi
Tray Loader
(MTL)
Intended spe-
cimen
Observable specimen Glass slide with cover glass
Size of glass slide Standard tray: width: 25mm 26.5mm, length:
75mm 76.5mm, thickness: 0.9mm - 1.2mm
Optional trays:
1) Width: 51mm 53mm, length: 75mm
76.5mm, thickness: 0.9mm - 1.2mm
2) Width: 100mm 102mm, length: 75mm
76.5mm, thickness: 0.9mm - 1.2mm
3) Width: 126mm 128mm (scanable area
restricted to 107mm), length: 75mm 76.5mm,
thickness: 1.1mm - 1.4mm
Size of cover glass Thickness: 0.12mm - 0.17mm
Optical frame Illuminator Built-in Koehler illumination for transmitted light
Objectives Compatible objectives 2x, 4x, 10x, 20x, 30x, 40x,
60x and 100x, selected oil and silicon immersion
objectives, Phase objectives
Motorized stage Motorized XY stage with automatic control
Focusing Motorized automatic control
Fluorescence Observation Motorized fluorescence illuminator
Motorized filter wheel
LED Fluorescence light source (Excelitas X-Cite
Turbo, X-Cite Xylis)
Camera sys-
tem
Brightfield 2/3” CMOS camera, 3.45µm x 3.45µm pixel size,
high sensitivity, high resolution
Fluorescence Olympus VS304 high sensitive, high resolution or
Hamamatsu ORCA Flash4.0 V3 and Orca Fusion
- 24 -
Instructions for use
8 Specifications
OLYMPUS VS200 System
