11 Mounting fluorescence components
11.7.4 X-Cite Turbo
The units described below must be assembled and adjusted by Olympus. If these units are
assembled or adjusted by the customer, the operations are not ensured.
The excitation filters in the X-Cite Turbo have to be placed as indicated in the boxes
in the picture below (the arrows show the filter orientation). Refer to the X-Cite
Turbo manual how to mount the filters.
- 61 -
Instructions for useOLYMPUS VS200 System
