11 Mounting fluorescence components
10. Configure the filter. See Device settings - filter auf Seite 88.
11.2.3 U-FFWO T3 (Motorized fast observation filter wheel)
The units described below must be assembled and adjusted by Olympus. If these units are
assembled or adjusted by the customer, the operations are not ensured.
Hex key (2.0) to lock the tubus
Hex key (3.0) to open the filterwheel
Small spanner to adjust the height of the tubus
Spanner to fix the tubus
1. Before you can mount the U-FFWO T3 you need to assemble the bottom
flange. The bottom flange is fixed with two 2.0mm hex socket screws.
For details refer to the U-FFWO manual.
- 49 -
Instructions for useOLYMPUS VS200 System
