8. Select the [Acquire] >[Devices] > [Device Settings] command to open the
[Device Settings] dialog box.
9. Configure the filter cube. See Device settings - filter auf Seite 88.
11.7.3 U-FDICT filter cube
The units described below must be assembled and adjusted by Olympus. If these units are
assembled or adjusted by the customer, the operations are not ensured.
Mount an optional U-FDICT for polarized light acquisition. The U-FDICT should be
placed into position 8 of the IX3-RFACA because this position is configured in the
default device settings.
1. Insert the U-FDICT into position 8 as shown in the image.
It is between the index 5 and 6.
Refer to chapter Activate the motorized polarizer auf Seite 86 and Setup
polarization (Pol) observation method auf Seite 94 to configure the system
to scan with polarized light.
If you would like to install other filter cubes please make sure that you register them
in the dialog box [Device Settings] later. See Device settings - filter auf Seite 88.
