View from above
View from below
9.2.2 Removing transportation lock from transmitted light condenser
(BX3-UCD8A)
The units described below must be assembled and adjusted by Olympus. If these units are
assembled or adjusted by the customer, the operations are not ensured.
ATTENTION
The transportation locks must be remounted each time before the unit is trans-
ported. Make absolutely sure not to lose the transportation locks and the
mounting material.
Hex screwdriver (2,5mm, 3mm)
1. Remove the six 2.5mm hex socket screws which hold the black tamper pro-
tection plate like shown in the image below.
- 28 -
Instructions for use
9 Unboxing
