11 Mounting fluorescence components
Finally the system should look like on the image below.
11.2 Fluorescence filter wheels or camera adapter for mono-
chrome camera
The units described below must be assembled and adjusted by Olympus. If these units are
assembled or adjusted by the customer, the operations are not ensured.
Depending on the customer’s configuration you either have to mount only one or
two fast filter wheels. The following chapter describes how to mount the different fil-
ter wheels.
11.2.1 U-FFWR (Motorized fast reflected light filter wheel)
The units described below must be assembled and adjusted by Olympus. If these units are
assembled or adjusted by the customer, the operations are not ensured.
