12. Push the bracket upwards until it attaches to the IX3-RFALFE and tighten
the two hex socket screws.
13. Make sure the power is switched off and attach the IX3-RFACA cable to the
socket at the back of the IX3-RFACA.
14. Attach the black tamper protection plate again and tighten the six hex
socket screws.
- 44 -
Instructions for use
11 Mounting fluorescence components
OLYMPUS VS200 System
