18 VS200 device configuration
18 VS200 device configuration
1. On the start page of the software click the [Device Settings] button.
The software will automatically switch to the [Manual control] layout
and open the [Device Settings] dialog box.
2. In the [Device Settings] dialog box click on the [Device List] button to open
the [Device List] dialog box.
3. VS200 ASW offers five predefined device configurations to choose from.
Depending on the configuration of your VS200 kit (FL light source, fast filter
wheels and filter set) select one of the five.
If you have a VS200 brightfield system there is only one (VS200)
device configuration available.
- 85 -
Instructions for useOLYMPUS VS200 System
