12 Assembly of the housing for scanner
the sockets.
12.3 Back panel
The back panel needs to be attached before mounting the top panels. It is
fixed with four knurled head screws.
The three knurled head screws at the top are part of the top panel and are
tightened later.
1. Guide the three cables from the backside of the VS200 system through the
back panel like shown in the image below.
- 65 -
Instructions for useOLYMPUS VS200 System
