18 VS200 device configuration
shading correction. See Shading correction for fluorescence observation
methods auf Seite 160.
18.7 VS200 LED lamp voltages
18.7.1 Orca Flash 4.0 voltages (%)
Observation method
Objective BFMono
(AS 75%)
DFMono
(AS max)
PHMono
(AS 75%)
2x PLN 0.6 not defined not defined
4x UPLFLN 0.6 - not defined
10x UPlanXApo 0.8 - -
20x UPlanXApo 0.5 not defined -
40x UPlanXApo 0.7 not defined -
40xUplanXApoS
60x UPlanXApoO - not defined -
100x UPlanXApoO - not defined -
18.7.2 Orca Fusion voltages (%)
Observation method
Objective BFMono
(AS 75%)
DFMono
(AS max)
PHMono (AS 75%)
2x PLN 1.8 not defined not defined
4x UPLFLN 1.2 100 not defined
10x UPlanXApo 1.8 100 60
20x UPlanXApo 2.1 not defined 100
40x UPlanXApo 5.7 not defined 100
40xUplanXApoS not defined 100
60x UPlanXApoO 6.8 not defined 100
100x UPlanXApoO 2.3 not defined 100
- 97 -
Instructions for useOLYMPUS VS200 System
