4-59
4-2 Function Mode
4
Functions
PID Enable/Disable and PID Integral Reset
The PID enable/disable function disables the PID function temporarily through terminal input. This
overrides the A071 setting to control the motor frequency. Also, the PID integral reset function
clears the PID integral value that has until then been integrated through terminal input. This helps
stop the motor when the frequency control is shifted to the PID control.
For details on the PID function, refer to "PID Function" (page 4-20).
UP/DOWN Function
This function changes the Inverter output frequency using UP and DWN terminals of the multi-
function inputs.
•While the UP/DWN terminal is turned on, the acceleration/deceleration time depends on F002,
F003/F202, and F203.
•You can store a frequency set value after UP/DWN adjustment. Choose whether to store the value
with C101.
Also, you can clear the stored frequency set value by allocating 29 (UDC) to the desired multi-
function input and turning on/off the UDC terminal.
Data Symbol Function name Status Description
23 PID PID enabled/disabled
ON Disables the PID function.
OFF Does not affect the PID function.
24 PIDC PID integral reset
ON Forcibly sets the PID integral value to zero.
OFF Does not affect the PID function
Related functions C001 to C005
Required settings A071=01
Data Symbol Function name Status Description
27 UP
UP/DWN function
accelerated
ON
Increases the current speed during the signal
input period.
OFF Keeps the current speed.
28 DWN
UP/DWN function
decelerated
ON
Decreases the current speed during the signal
input period.
OFF Keeps the current speed.
29 UDC
UP/DWN function data
clear
ON Clears the stored UP/DWN speed.
OFF Keeps the stored UP/DWN speed.
Related functions C001 to C005
Required settings A001 = 02, C101
