7-1 Standard Specification List
7
Specifications
7Specifications
7-1 Standard Specification List
3-phase 200-V Class
Item 3-phase 200-V class
Model name (3G3JX-) A2002 A2004 A2007 A2015 A2022 A2037 A2055 A2075
Applicable motor
capacity
*1
kW 0.2 0.4 0.75 1.5 2.2 3.7 5.5 7.5
HP1/41/212357.510
Rated output
capacity (kVA)
200V 0.4 0.9 1.3 2.4 3.4 5.5 8.3 11.0
240 V 0.5 1.0 1.6 2.9 4.1 6.6 9.9 13.3
Rated input voltage 3-phase (3-wire) 200 V -15% to 240 V +10%, 50/60 Hz ±5%
Built-in filter Radio noise filter
Rated input current (A) 1.8 3.4 5.2 9.3 13.0 20.0 30.0 40.0
Rated output voltage
*2
3-phase: 200 to 240 V (for input voltage)
Rated output current (A) 1.4 2.6 4.0 7.1 10.0 15.9 24.0 32.0
Weight [kg] 0.8 0.9 1.1 2.2 2.4 2.4 4.2 4.2
Cooling method Self-cooling Forced-air-cooling
Braking
torque
At short-time
deceleration
*3
At capacitor feedback
Approx. 50%
Approx. 20% to
40%
Approx. 20%
DC injection braking
Injection braking frequency/time, braking force variable,
frequency control available
