Omron 3G3JX

7-19
7-5 Options
7
Specifications
Input Noise Filter (3G3AX-NFI)
Dimensional Drawing
3G3AX-NFI21
3G3AX-NFI22
3G3AX-NFI23/3G3AX-NFI24
3G3AX-NFI41/3G3AX-NFI42
3G3AX-NFI43/
Inverter side
66
52
(10)
L3' L2' L1'
L3 L2 L1
(84)
100
117
2-φ5.0
10
M4
67MAX
(15)
Power supply
side
Model
Dimensions (Unit: mm)
ABCD
3G3AX-NFI23 128 118 56 10
3G3AX-NFI24 144 130 56 11
3G3AX-NFI41 144 130 56 11
3G3AX-NFI42 144 130 56 11
3G3AX-NFI43 144 130 56 11
Inverter side
Power
supply side
φ5
L3' L2' L1'
L3 L2 L1
A
B
(95)
74
C
(D)
5
M4
(15)
73
