4-5
4-2 Function Mode
4
Functions
4-2 Function Mode
<Group F: Basic Function Parameter>
Output Frequency Setting/Monitor
•Set the Inverter output frequency.
•With the frequency reference set to the Digital Operator ([A001] = 02), you can set the output
frequency in F001. For other methods, refer to the [A001] section in "Frequency Reference
Selection" (page 4-7).
•If a frequency is set in [F001], the same value is automatically set in multi-step speed reference 0
[A020]. To set the 2nd multi-step speed reference, use [A220], or use [F001] with the SET terminal
turned on.
To set by using the SET terminal, allocate 08 (SET) to the desired multi-function input.
* To switch to the 2nd multi-step speed, allocate 08 (SET) to the multi-function input terminal and then turn it on.
Acceleration/Deceleration Time
Set an acceleration/deceleration time for the motor. For a slow transition, set a large value, and for
a fast transition, set a small one.
* To switch to 2nd acceleration/deceleration time 1, allocate 08 (SET) to the multi-function input terminal and then
turn it on.
Parameter No. Function name Data Default setting Unit
F001
Output frequency
setting/monitor
0.0/Starting frequency to Max.
frequency
6.0 HzA020
Multi-step speed
reference 0
*
A220
2nd multi-step
speed reference 0
Related functions A001, A201, C001 to C005
Parameter No. Function name Data Default setting Unit
F002 Acceleration time 1
0.01 to 3000 10.0 s
*
F202 2nd acceleration time 1
F003 Deceleration time 1
*
F203 2nd deceleration time 1
Related functions A004, A204, C001 to C005
