4-48
4-2 Function Mode
4
Functions
•You can also select a multi-step speed by turning on/off the multi-step speed terminals (CF1 to
CF4) and set the multi-step speed frequency with F001.
Jogging Operation
This function allows you to determine and fine-tune the motor stop position.
•Allocate 06 (JG) to the desired multi-function input.
Multi-step speed
Multi-step speed terminals Reflected speed
CF4CF3CF2CF1
0th
0
0
0
0 Reference source according to the A001 setting
1st 1 A021
2nd
1
0A022
3rd 1 A023
4th
1
0
0A024
5th 1 A025
6th
1
0A026
7th 1 A027
8th
1
0
0
0A028
9th 1 A029
10th
1
0A030
11th 1 A031
12th
1
0
0A032
13th 1 A033
14th
1
0A034
15th 1 A035
Data Symbol Function name Status Description
06 JG Jogging operation
ON Operates at the set jogging frequency.
OFF Stop
Related functions C001 to C005
Required settings A002 = 01, A038 > b082, A038 > 0, A039
Parameter No. Function name Data Default setting Unit
A038 Jogging frequency 0.00/Starting frequency to 9.99 6.00 Hz
A039 Jogging stop selection
00: Free-run stop
01: Deceleration stop
02: DC injection braking stop
00 Hz
